NEO-8Q / NEO-M8 - Hardware integration manual
UBX-15029985 - Production information Appendix Page 27 of 29
C1-Public
Appendix
A Glossary
Abbreviation Definition
ANSI American National Standards Institute
BeiDou Chinese navigation satellite system
CDMA Code Division Multiple Access
EMC Electromagnetic compatibility
EMI Electromagnetic interference
EOS Electrical Overstress
EPA Electrostatic Protective Area
ESD Electrostatic discharge
Galileo European navigation system
GLONASS Russian satellite system
GND Ground
GNSS Global Navigation Satellite System
GPS Global Positioning System
GSM Global System for Mobile Communications
IEC International Electrotechnical Commission
PCB Printed circuit board
QZSS Quasi-Zenith Satellite System
Table 5: Explanation of the abbreviations and terms used
B Recommended parts
Recommended parts are selected on data sheet basis only. Other components may also be used.
Part Manufacturer Part ID Remarks Parameters to consider
Diode
ON
Semiconductor
ESD9R3.3ST5G Standoff voltage>3.3 V Low capacitance < 0.5 pF
ESD9L3.3ST5G Standoff voltage>3.3 V
Standoff voltage > Voltage for active
antenna
ESD9L5.0ST5G Standoff voltage>5 V Low inductance
SAW TDK/ EPCOS B8401: B39162B8401P810 GPS+GLONASS High attenuation
TDK/ EPCOS B3913: B39162B3913U410 GPS+GLONASS+BeiDou For automotive application
TDK/ EPCOS B4310: B39162B4310P810 GPS+GLONASS Compliant to the AEC-Q200 standard
ReyConns NDF9169 GPS+BeiDou
Low insertion loss, only for mobile
application
Murata SAFFB1G56KB0F0A GPS+GLONASS+BeiDou
Low insertion loss, only for mobile
application
Murata SAFEA1G58KB0F00 GPS+GLONASS
Low insertion loss, only for mobile
application
Murata SAFEA1G58KA0F00 GPS+GLONASS
High attenuation, only for mobile
application
Murata SAFFB1G58KA0F0A GPS+GLONASS
High attenuation, only for mobile
application
