UB+ EUPHO E3 User Manual

6 7
CHARGING THE SPEAKER
The EUPHO E3 goes into standby mode, as represented by the breathing
Bluetooth light to conserve energy, if there is no Bluetooth connection. The
EUPHO E3 shuts itself down after another 10 minutes of inactivity. During
standby mode, press any button to activiate the speaker.
When the battery level drops to below 10%, there will be an intermittent
alert sound to indicate the low battery status.
YoucanndoutthebatterylevelbypressingthePowerbutton.
The battery level will be represented by the number of EQ Mode lights being
lit, one light being 25% and four lights being 100%. This function is only
valid when the speaker is switched on.
Connect the USB cable to
the plug and to the micro
USB port on the EUPHO E3.
When the cable is plugged
in to the electricity outlet,
the EUPHO E3 will start to
charge as represented by the
red light.
The red light will go off when
charging is completed.
Note: The USB cable and
plug are not included with
the package.

UB+ EUPHO E3 Specifications

General

Certification	CE, FCC, RoHS
Product color	White
Recommended usage	Universal
USB charging	Yes
Speaker type	-
Speaker placement	Floor
Audio output channels	- channels
Impedance	4 Ω
Sensitivity	100 dB
Frequency range	35 - 17000 Hz
RMS rated power	60 W
Peak Music Power Output (PMPO)	25 W
USB connector type	Micro-USB, USB Type-A
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Cables included	USB
Power source type	Battery
USB output voltage	5 V

Weight and Dimensions

Depth	355 mm
Width	375 mm
Height	357 mm
Weight	1500 g
