UB+ EUPHO E3 User Manual

16 17
OTHER INPUTS
Other than Bluetooth,
there are other inputs that
can work with the EUPHO
E3. Note: Cables are not
included in this package.
The inputs are prioritised in
this order - Bluetooth, USB
and then optical.
The 3.5mm auxillary input
will override the rest of the
inputs when the aux cable
is plugged into the speaker.
The speaker will restart when
the cable is plugged out.
This ensures that the EUPHO
E3 can be safely used as a
microphone or instrument
speaker with no potential
interruption from other
sources.
OTHER FUNCTIONS & CONTROLS
• PURGING LIST OF SAVED BLUETOOTH DEVICES
Press both the Bluetoth button and the Volume down button together to
purge the list of saved Bluetooth devices. The Bluetooth light and the TWS
L light will blink ten times to signify the successful purge.
• POWERBANK FUNCTION
The EUPHO E3 can also be used as a powerbank
through the USB port to charge mobile devices on
the go.
USB
Optical
Aux

UB+ EUPHO E3 Specifications

General

Certification	CE, FCC, RoHS
Product color	White
Recommended usage	Universal
USB charging	Yes
Speaker type	-
Speaker placement	Floor
Audio output channels	- channels
Impedance	4 Ω
Sensitivity	100 dB
Frequency range	35 - 17000 Hz
RMS rated power	60 W
Peak Music Power Output (PMPO)	25 W
USB connector type	Micro-USB, USB Type-A
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Cables included	USB
Power source type	Battery
USB output voltage	5 V

Weight and Dimensions

Depth	355 mm
Width	375 mm
Height	357 mm
Weight	1500 g
