UE ONE Series User Manual

IM_1XSW-02
www.ueonline.com
20
4”, 6”, 10”
[101.6, 152.4, 254] mm
(FIXED DIM.’S)
Ø0.250
[6.35] mm
316 st/st
SHEATH
WELD
1/2” NPT HEX FITTING
300 SERIES st/st
22 AWG STRANDED
TEFLON INSULATION
4.50
[114.3] mm
(FIXED DIM.)
EPOXY SEAL
0.94
[23.87] mm
(FIXED DIM.)
4.50
[114.3] mm
(FIXED DIM.)
EPOXY SEAL
1/2” NPT
HEX FITTING
300 SERIES st/st
22 AWG STRANDED
TEFLON INSULATION
1/2” NPT
UNION
300 SERIES st/st
316 st/st
SHEATH
Ø0.250
[6.35] mm
0.25
[6.35] mm
SPRING
LOAD
L DIM.
(CUSTOMER SUPPLIED DIM.)
0.50
[12.7] mm
NUN DIM.
(CUSTOMER SUPPLIED DIM.)
L DIM.
(CUSTOMER SUPPLIED DIM.)
2.5
[63.5] mm
Ø0.250
[6.35] mm
Ø0.125
[3.18] mm
300 SERIES st/st
MINERAL INSULATED CABLE
Ø0.125, [3.18] mm (FOR DC UNITS)
Ø0.250
[6.35] mm
1/2” NPT COMPRESSION FITTING
300 SERIES st/st
26 AWG STRANDED
TEFLON INSULATION
4.50
[114.3] mm
(FIXED DIM.)
EPOXY SEAL
2.00
[50.8] mm
(FIXED DIM.)
1/2”-14 NPT
PIPE NIPPLE
300 SERIES st/st
0.50
[12.7] mm
Temperature Sensors
Remote (TR1, TRC, TH1, THC, TC1, TCC)
SENSOR OPTIONS
Spring Loaded Local (TTC)
Fixed Local (TL1 - TL3)
Differential Pressure
1/4”-18 NPT (MALE)
BOTH ENDS
3.0
[76.2mm]
1.06
[26.9mm]
Gauge Pressure
1.06
[26.9mm]
1/2”-14 NPT (FEMALE)
Pressure Sensors
5.30”
[134.6mm]
2.44”
[61.9mm]
2.86”
[72.6mm]
[221mm]
8.70”
DUAL SEAL
ENCLOSURE
1/8" NPT
ANNUNCIATION
VENT CAN BE
ROTATED UP TO
90° IN EITHER
DIRECTION
Dual Seal with Gage Pressure
Sensor (Option M041)
0.375 REF
0.250
REF
2.50
REF
SENSOR
THERMOWELL ADAPTER
[6.35] mm
[63.5] mm
[9.53] mm
Thermowell Adapter Kit Option W081
(UE Part #62169-44)
