UE ONE Series User Manual

IM_1XSW-02
www.ueonline.com
6
PLC
D
IN
1
D
IN
2
COM
PWR
PLC
D
IN
1
D
IN
2
L2/N
L1/H
7.8-50 VDC
Common
SW and IAW
PLC Inputs Circuit
PLC
D
IN
2
COM
PWR
COM
RELAY
Common
Interposing
Relay with
IAW Circuit
70-240 VAC/VDC
L1/H/+
PLC
D
IN
2
COM
PWR
COM
RELAY
7.8-50 VDC
7.8-50 VDC
70-240 VAC/VDC
L2/N/-
Common
L1/H/+
L2/N/-
1XSWLL
1XSWLL
1XSWHL
1XSWHL
WIRING DIAGRAMS - Models 1XSWLL and 1XSWHL
Maximum Switch Ratings – Flameproof and Non-Incendive
Model Signal Name Voltage Rating Current Rating
1XSWLL
SW 7.8 – 50.0 VDC 0.1 amperes
1
IAW 7.8 – 50.0 VDC 0.1 amperes
1
1XSWHL
SW 70 – 240 VAC/VDC 0.1 amperes
1
IAW 7.8 – 50.0 VDC 0.1 amperes
1
1XSWHH
SW 70 – 240 VAC 0.150 – 10 amperes
2
IAW 7.8 – 50.0 VDC 0.1 amperes
1
1
Derate at 0.001 amperes per ˚C above 25˚C
2
Derate at 1 ampere per 5.5˚C above 38˚C ambient
Table 2
Figure 4 Figure 5
Figure 6 Figure 7
