3
FUNCTIONS
FEATURES
• 1000V AC/DC
• 10A AC/DC
• Resistance 40MΩ
• Diode test
• Audible continuity
• Capacitance 9999μF
• Milliamps/Microamps
• Auto/Manual ranging
• Auto power off
• Min/Max
• Hold
• 1 ms Fast response Min/Max
• Low battery indicator
• Test lead holders
• Kick stand
• High resolution backlit display
• Auto selection
• Fused test lead inputs
• Rubber boot
GENERAL SPECIFICATIONS
• Operating Temperature: 32˚ to 122˚F (0˚ to 50˚C)
• Storage Temperature: -44˚ to 122˚F (-20˚ to 50˚C)
• Operating Humidity: <75% max.
• Operating Altitude: 6561 ft (2000m)
• Display: 6,000 count
• Backlight: Yes
• Over-range: “OL” is displayed
• Dimensions: 6.49” x 3.3” x 2.17”
• Item Weight: 15.0 oz
• Calibration: Recommended annually
• CAT Rating: CAT III 600V/CAT II 1000V
• Certifications: cELTus UL 61010-1:2012 3rd
CE EN 61010-1:2010 3rd, IEC61010-2-033:2012, Ed.1, EN 61326-1:2013
FCC, RoHS Compliant, TOV protection, IP 42, 6’ Drop protection
• Battery Type: (AA) 2
• Test Leads: CAT III test leads
• Accuracy: ± (% of reading + # of least significant digits)
Measurement Category Short-Circuit (typical) kA
a
Location in the building installation
II < 10
Circuits connected to mains socket outlets and similar
points in the MAINS installation
III < 50 Mains distributions parts of the building
IV > 50 Source of the mains installation in the building
CATEGORY DEFINITIONS
