UEi DM505 User Manual

7
Ranges Accuracy Resolution Overload Protection
600Ω to 6MΩ ±(0.8% +5 dgts) 0.1Ω to 0.001MΩ
600V
40MΩ ±(1.5% +5 dgts) 0.01MΩ
Features:
RANGE
MIN/MAX
HOLD
WARNING
• Do not measure resistance on a live circuit.
Resistance: <40MΩ
Open Circuit Voltage Audible Threshold Overload Protection
Approx.: <1.0V Approx.: 40Ω 600V
Features:
MIN/MAX
HOLD
• Buzzer sounds at less than 40Ω.
WARNING
• Do not measure resistance on a live circuit.
Continuity
RANGE
SEL
MIN/MAX HOLD
FAST
V
Apo
A
μA
mAμA
A
mA
10A
MAX
FUSED
400mA
MAX
FUSED
MAX
CAT III
600V
CAT II
1000V
DM505
A
μA
mA
Apo
AT
DM505
RANGE
SEL
MIN/MAX HOLD
FAST
V
Apo
A
μA
mAμA
A
mA
10A
MAX
FUSED
400mA
MAX
FUSED
MAX
CAT III
600V
CAT II
1000V
DM505
A
μA
mA
Apo
DM505
w ww. . com
information@itm.com1.800.561.8187
