MK STRUCTURE
STRUCTURESTRUCTURE
STRUCTURE
In general, they are tied directly to the main
structures with pins D40 allowing of a fast and safe
on-site assembly.
Hanging structure in a MK deck flange form carrier
Hanging structure in a MK deck flange form carrierHanging structure in a MK deck flange form carrier
Hanging structure in a MK deck flange form carrier
Hanging structure in a MK vertical formwork
Hanging structure in a MK vertical formworkHanging structure in a MK vertical formwork
Hanging structure in a MK vertical formwork carrier
carriercarrier
carrier
Hanging structure in a MK cut
Hanging structure in a MK cutHanging structure in a MK cut
Hanging structure in a MK cut-
--
-and
andand
and-
--
-cover tunnel form carrier
cover tunnel form carriercover tunnel form carrier
cover tunnel form carrier
4.1.3. Structure of form carriers
Such structures must only bear their self-weight plus
the formwork they hold. They are medium load-
bearing capacity structures and light, in general.
MK
MKMK
MK parapet form carrier structure
parapet form carrier structureparapet form carrier structure
parapet form carrier structure
The horizontal braces and diagonals are tubes in all
directions, reserving the walers for the most
demanding areas of the structure, in this case, to
connect levelling and rolling elements.
The rolling and levelling parts have lower load-
bearing capacity: 150 kN and 60 kN for the jacks and
25 kN for the wheels.
Occasionally, when these structures are submitted to
concrete loads caused by lateral forces or they
support single-sided wall formwork, walers are used
to reinforce the horizontal axis.
MK vertical formwork carrier structure
MK vertical formwork carrier structureMK vertical formwork carrier structure
MK vertical formwork carrier structure
