10 GB
Operation / Maintenance and care / Service / WarrantyOperation
appliance remains in trickle-charge mode, even if
the user switches over to another mode. This pro-
tects the battery from being damaged.
Q
Mode 1 „6 V“ (7.3 V / 0.8 A)
This mode is suitable for charging 6 V lead-acid
batteries with a capacity less than 14 Ah.
Press the selection button MODE
9
, to select
mode 1. After doing so, the corresponding LED
display „6 V“
2
lights up. If you do not activate
an-other process afterwards, the electronic sys-
tem will automatically start the charging process
together with the LED display
8
at with a
current of 0.8 A ± 10 %. If the procedure runs
without any problems, the LED display
8
remains on during the entire charging proc
ess,
un-
til the battery is fully charged at 7.3 V / ±
0.25 V.
When the battery is fully charged, LED display
7
lights up and LED display
8
goes
out. The device now switches automatically into
maintenance charging mode.
Q
Mode 2 „12 V“ (14.4 V / 0.8 A)
This mode is suitable for charging 12 V lead-acid
batteries with a capacity less than 14 Ah.
Press the selection button MODE
9
, to activate
mode 2. After completion of this process, the
appropriate LED indicator
3
lights up.
Then if you do not take any further action, the
electronic control and the LED indicator
8
automatically switches on and starts the charg-
ing process. If the procedure runs without any
problems, the LED display
8
remains on
during the entire charging process, until the
battery is fully charged. When the battery is
fully charged, LED display
7
lights up and
LED display
8
goes out. The device now
switches automatically into maintenance charg-
ing mode.
Q
Mode 3 „12 V“ (14.4 V / 3.8 A)
This mode is mainly suitable for charging 12 V
lead-acid batteries with a capacity greater than
14 Ah under normal conditions.
Press the selection button MODE
9
, to activate
mode 3. Then if you do not take any further ac-
tion, the electronic control and the LED indicator
4
switches on and starts the charging pro-
cess. If the process runs without any problems,
the LED indicator
8
remains on during the
whole charging process until the battery is
charged. When the battery is fully charged, the
LED indicator
7
and the die LED indicator
8
go out. The device now switches auto-
matically into maintenance charging mode.
Q
Mode 4 „12 V” (14.7 V / 3.8 A)
This mode is used for charging 12 V lead-acid bat-
teries with a capacity greater than 14 Ah under
cold conditions or for charging some AGM (Absor-
bent Glass Mat) batteries with a capacity greater
than 14 Ah.
Press the MODE selection button
9
to select
mode 4. As you select the desired mode, the
appropriate LED indicator
5
lights up im-
mediately. If you take no further action, the elec-
tronic control switches on after a preset delay
to begin the charging process. In this mode the
charging current is the same as in “mode 3”. If
the process runs without any problems, the LED
indicator
8
lights up, the electronic control
switches on and remains in this state until the
battery is charged. As soon as this point is
reached, the battery charger switches to main-
tenance charging mode. Now the LED indicator
8
goes out and the LED indicator
7
lights up to indicate the present status.
