FUSE PROTECTION- A blown fuse indicates a problem that
should be corrected before the fuse is replaced. Always replace
with the same value fuse. Never substitute a larger value fuse.
2.4 Operation- Location of Terminals,
Controls and LED indicators
TA4600, TA4320TA4600, TA4320
1. RCA input jacks 2. High level input 3. Input level adjust
4. Crossover select 5. Low pass freq. 6. High pass freq.
7. Bass boost 8. Mode 9. Power L.E.D.
10. Protection L.E.D.
1. Power terminals 2. Fuse(s) 3. Speaker terminals
