Ultimate TA4600 - Page 11

9
TA2300, TA2160TA2300, TA2160
1. RCA input jacks 2. High level input 3. Input level adjust
4. Bass Boost 5. Low pass freq. 6. Crossover
select 7. High pass freq. 8. Power L.E.D. 9. Protection L.E.D.
1. Power terminals 2. Fuse 3. Speaker terminals
+12V
POWER
RMT GND
SPEAKER
( A+ ) ( A- ) ( B- ) ( B+ )
FUSE
15A
BRIDGED
( + )
( - )
312
HIGH LEVEL
L
R
MIN MAX
INPUT L E V E L
BASS-BOOST
ON OFF
40 240
LPF
FULL
HPF
LPF X-OVER HPF
40 240
PROTECTPOWER
8 2 1 3 4 5 6 7 9
