STARTUP
2.1
STARTUP
Unpacking
1. Carefully remove crate from the skid.
2. Remove machine from skid.
3. Wipe down outside of the machine.
Power Requirements
The machine is available with a 7½ horsepower vacuum pump for the 200mm (8-in.) model
and a 10 horsepower vacuum pump for the 300mm (12-in.) model. The standard machine
is rated 220 volt, 60 Hertz, 3 phase and is supplied with a 30 amp, 250 volt, 3 phase plug.
The owner must supply the correct 3 phase or single phase power source in accordance
with the National Electric Code. The table below is based on the National Electric Code and
is to be used as a guide in wire size selection and short circuit protection. The requirements
noted in the table may change. Please consult an electrician prior to installation.
UV2100 POWER CABLE SIZING CHART
208/230v (5&7.5hp Pumps) 10 gauge/ 4 conductor
380v 12 gauge/ 5 conductor
460v 10 gauge/ 4 conductor
208/230v (10&12hp Pumps) 8 gauge/ 4 conductor
380v w/o neutral 12 gauge/ 4 conductor
Customer Voltage
Pump Motor Full Load Amps
Supply conductor shall Supply conductor shall
have an ampacity not have an ampacity not
less than 125% of the less than 125% of the
Pump Motor Full Load Pump Motor Full Load
AmpsAmps
5 HP 7.5 HP 10 HP 12 HP
208, 60 Hz 3 Phase 21 26.5 32
230, 60 Hz 3 Phase 20.5 26 30
380, 50 Hz 3 Phase 12 14 15
460, 60 Hz 3 Phase 10.5 13 15
575, 60 Hz 3 Phase 9 10.5 12.5
230, 60 Hz Single Phase 22.5 - - -
Customer Voltage
Inverse Time Circuit
Breaker
Fused Disconnect Dual
Element (Time Delay)
5 HP 7.5 HP 10 HP 12 HP 5 HP 7.5 HP 10 HP 12 HP
208, 60 Hz 3 Phase 50 60 70 35 45 50
230, 60 Hz 3 Phase 50 60 60 35 45 50
380, 50 Hz 3 Phase 25 30 35 20 20 25
460, 60 Hz 3 Phase 25 30 35 15 20 25
575, 60 Hz 3 Phase 20 25 30 15 15 20
230, 60 Hz Single Phase 60 - - - 45 - - -
