ULTRASOURCE ULTRAVAC 2100 User Manual

Model 0165 0205 0255 0305
Nominal pumping speed (ACFM) 115 130 170 196
Free air displacement (CFM) 117 141 180 212
End Vacuum (Torr) .5 .5 .5 .5
End Vacuum (inches Hg) 29.9 29.9 29.9 29.9
Maximum sound level (dBA) 79 80 81 81
Motor size - 3 phase (HP) 7.5 7.5 10 12
Nominal motor speed (RPM) 1750 1750 1750 1750
Motor frame size 213TC 213TC 215TCZ 215TCZ
Nominal motor amps (@230/460v) 20.4/10.2 20.4/10.2 25.6/12.8 29/14.9
Oil capacity (Quarts) 6.9 6.9 6.9 6.9
Inlet connection (NPT) 2" 2" 2" 2"
Exhaust connection (NPT) 2" 2" 2" 2"
Approximate weight (lbs.) 416 435 460 575
TECHNICAL DATA
13
