OVERVIEW
- 1 -
1. OVERVIEW
The Model GP-1GRY is a constant temperature type Pirani vacuum gauge utilizing heat conduction of
gas.
If the sensor head burns out, the meter indication will deflect off-scale to the higher pressure side
(atmospheric pressure side).
Pressure can be set at two points by meter relay and the comparator output can be taken out as setpoint
(transfer type).
1.1. Specifications
Name
Pirani vacuum gauge
Model
GP-1GRY
Measurable range
0.4 to 2700 Pa (0.003 to 20 Torr)
Measurement error
Within ± 3% of 100% full scale as converted to linear scale
(Refer to 5.3)
Power requirements
AC100
～
240V,10VA
Power cable
3m
Outlet side
：
PLUG TYPE B
Operating temperature range
10 to 40°C
Operating humidity rang
15 to 80%
（
No condensation
）
Recorder output
0 to 10 mV DC
Fuse rating
250 V, 0.5 A
Relay contact capacity
Max.AC125V/1A
、
AC250V/0.5A
、
DC30V/2A
Min. DC10
ｍ
V/10
μ
A
Outside dimensions (mm)
Controller: 90W × 140D × 100H
A-type meter: 100W × 111D × 100H
Weight
Controller: 1000g
A-type meter: 440g
Measuring unit: 35g(GP-H)
1.2. Standard Accessories
Quick manual
paper
1 pc.
1.3. Options
1.3.1. Sensor head
Sensor head
WP-01, WP-02, WP-03., WP-16
WPB-10, WPB-10-034
Connecting flange
WP-01:
φ
18 port, WP-02:
φ
15 port
WP-03:R3/8, WP-16(NW16)
WPB-10:UFC034
WPB-10-034:UFC034
Filament material
Pt
Pt
Other materials
BS/Ni-plating
Ni、Kovar、Glass、SnSbCu
SUS304
、
Cu(Gasket)
FeNiCo(Ni-plating)
、
Al
2
O
3
Weight(g)
WP-01
：
about 26
、
WP-02
：
about 45
WP-03
：
about 63
、
WP-16
：
about 77
about 173
Internal volume(cm
3
)
WP-01
：
about 19
、
WP-02
：
about 17
WP-03
：
about 17
、
WP-16
：
about 22
about 18
Pressure max
※
1
< 2
×
10
+5
Pa(abs)
< 2
×
10
+5
Pa(abs)
Bakeout
※
2
80
℃
max
250
℃
max
*1:The breakdown pressure of the flange and clamp are to be considered otherwise.
*2:Bakeout temperature is a temperature of the sensor unit. Please remove the electronics(GP-H) or the
conversion cable(GP-BH).
