RELATED DRAWINGS
- 27 -
9. RELATED DRAWINGS
B-TYPE
CABLE LENGTH BETWEEN CONTOROLLER AND
METER ABOUT 1m
SENSOR HEAD
CABLE 2-100m
A-TYPE
C-TYPE
CONTOROLLER
CONVERSION
CABLE WP04 , 05
(2m)
MEASURING UNIT
GP-BH
MEASURING UNIT
GP-BH
CONVERSION
CABLE WPB-10
(2m)
Fig. 10 Meter/controller connection diagram
