EYEXO INSTALL GUIDE
QED IGNITE
Sticker Placement
Irons & 7 Groove
1. The area where the sticker is applied differs. Depending on the number of grooves where the
length of the groove starts to reduce.
2. If there are 7 grooves of different sizes on the club face, attach it to the top section based on
the 1/3rd difference on the 3rd groove of the shortening grooves
3. In this diagram, the sticker should be close to the Top Edge lined up with the 1/3rd difference
between groove “2” and “3.” Make sure the pointed cut is closest to the face of the club
QED USER MANUAL 26
Iron
