UNI Geräte EVSA - Technical Specifications; Dimensions with Standard Solenoid Drive

Technical specifications
03/2021 221.100.002-00 5
www.uni-geraete.com
6 Technical specifications
Further information on the electrical data can be found on the nameplate and in the operating instructions for
the specific solenoid drive.
6.1 Dimensions with standard solenoid drive
Threaded connection according to DIN ISO 228-1
4-EVSA 10-EVSA 16-EVSA 25-EVSA 40-EVSA
Valve class A
Group 2
Operating pressure
0 – 400 kPA
0 – 4 bar
0 –
1000 kPA
0 – 10 bar
0 –
1600 kPA
0 – 16 bar
0 –
2500 kPA
0 – 25 bar
0 –
4000 kPA
0 – 40 bar
Medium temperature
- Standard
- Optional
-20 °C to +60 °C
See nameplate
Ambient temperature -20 °C to +60°C
Supply voltage
- Direct current
- Alternating current
12 V – 440 V (–15% to +10%)
24 V – 500 V (–15% to +10%) (40–60 Hz)
Power consumption 10 – 4000 W
Degree of protection IP54 or IP65
Opening times 0.3 s – 0.7 s
Closing times < 1 s
Switching cycles see operating instructions for solenoid drive
Installation position (see name-
plate)
Vertical actuator:
Horizontal actuator:
Connection G Dime
nsion
1/4* 3/8 1/2 3/4 1 1 1/4 1 1/2 2
Overall length A 60 80 80 95 105 120 150 170
4/10-EVSA B 190 220 220 220 260 290 345 380
B` 240 305 305 310 370 400 495 525
ØC 83 106 106 106 127 127 153 153
D 22.5 22.5 22.5 21 30 40 50 50
40-EVSA B --210-----
B` --330-----
ØC --127-----
D --22.5-----
*G1/4 only in 4-EVSA version
