6.2 Assignment of solenoid drive types MG...
(*) Test pressure for checking the external tightness. This check is not a functional test.
Actuator types with “A” consist of pick-up and holding coil.
Type test CE-0085AR0256 for all valves except:
Acceptance test certificate 3.2 possible
– not available
Maximum valve load due to pipeline forces
The specified torques must not be applied for longer than 10 s.
1)
Not applicable for valves with flanges
Connection
G
1/4
(2)
3/8
(3)
1/2
(5)
3/4
(7)
1
(10)
1 1/4
(12)
1 1/2
(15)
2
(20)
Test pres-
sure (*)
PT
4-EVSA 005-3 008-2 008-2 008-2 010 012 014 016 PT10
10-EVSA – 008-2 008-2 008-2 010A5 012A5 014A5 016A5 PT16
40-EVSA ––012–––––PT40
DN flange
ANSI flange
PN 15
(5N)
1/2”
20
(7N)
3/4”
25
(10N)
1”
32
(12N)
1 1/4”
40
(15N)
1 1/2”
50
(20N)
2”
Test pres-
sure (*)
PT
4-EVSA 16 008-2 008-2 010 012 014 016 PT10
10-EVSA 16 010 010 010 012A5 014A5 016A5 PT16
16-EVSA 16 – –
018 – 018 – PT25
25-EVSA 40 – – – – – 019A5 PT40
40-EVSA 40 018 – 018 – – – PT40
DN flange
ANSI flange
PN 65
(25N)
2 1/2”
80
(30N)
3”
100
4”
125
-
150
6”
Test pres-
sure (*)
PT
4-EVSA 16 018 019A5 018A1 018A1 019A2 PT10
10-EVSA 16 019A5 018A1 018A1 019A1 019A2 PT16
16-EVSA 16 –
018A1 – – – PT25
25-EVSA 40 – – – – – PT40
40-EVSA 40
019A3.1 – – – – PT40
DN 8101520253240 50 65 80 100125≥150
Torsion
1)
Nm 20 35 50 85 125 160 200 250 325 400 – – –
Bending Nm 35 70 105 225 340 475 610 1100 1600 2400 5000 6000 7600
