Technical specifications
03/2021 221.100.002-00 7
www.uni-geraete.com
DN flanges Dimen-
sion
65 80 100 125 150
Overall length A 290 310 350 400 480
ANSI flanges Dimen-
sion
21/2” 3” 4” - 6”
4-EVSA B 430 440 470 510 550
B` 590 600 630 670 710
ØC 194 194 194 194 194
D 90 110 143 151 167
10-EVSA B 430 440 470 510 550
B` 590 600 630 670 710
ØC 194 194 194 194 194
D 90 110 143 151 167
16-EVSA B - 440 - - -
B` - 600 - - -
ØC - 194 - - -
D - 110 - - -
25-EVSA B -----
B` -----
ØC -----
D -----
40-EVSA B 470 - - - -
B` 630 - - - -
ØC 194 - - - -
D 90 - - - -
A = overall length acc. to DIN (e.g. ANSI flanges and DIN overall length or DIN flanges and overall length)
Overall length according to ANSI (see data sheet for overall fitting lengths DIN / ANSI 225.100.026 on our
homepage)
B` = dimension for removal of the solenoid drive
For solenoid drives for Ex-protection zone 1, the dimensions B and ØC change.
Observe dimensions for actuators with attached control system. (see operating instructions for solenoid
drive)
