Table 4 Product’s Components
No.
Parts’ Name
Description
1
Front Panel
Front panel contains the knobs
2
Produt’s Module
Product’s module contains the front module and the rear module
3
Rear Panel
Front Module
Figure 4 Exploded View of Front Panel
Table 5 Components of Front Panel
No.
Parts’ Name
Description
