UT131 Palm Size Multimeter
Notes:
*. Do not measure voltage over 250Vrms, or it may expose users to electric shock and damage the
device. If the range of the voltage to be measured is unknown, select the maximum range and
reduce accordingly.
*. Please pay extra attention when measuring high voltage in order to avoid electric shock.
*. Before using the device, it is suggested to measure a known voltage for verification.
2. Resistance measurement (see Figure 2b)
1) Switch the dial to “Ω” position.
2) Insert the black test lead into the COM jack, the red test lead into the “VΩmA” jack. Connect
test leads with the resistor in parallel
