UNI-T UT20B User Manual

Accuracy Specifications (2)
C. Square Wave Output
Range
Remark
Output approx. at 50Hz square wave. As a simple signal
source with 47kΩ resistance output.
B. DC Current
Range
2000µA
20mA
200mA
Resolution
1µA
10µA
100µA
Accuracy
(2.5%+10)
Overload Protection
0.2A, 250V fast type fuse, φ5x20mm.
25
Model UT20B: OPERATING MANUAL

UNI-T UT20B Specifications

General

Diode test	Yes
Product type	Digital multimeter
DC current range	0.2 - 2 A
DC voltage range	0.2 - 300 V
Statistic function	Maximum
Basic accuracy (DC current)	±(2.5%+10)
Basic accuracy (DC voltage)	±(1.5%+2)
Basic accuracy (resistance)	±(2.5%+5)
Dimensions (WxDxH)	52 x 26 x 95 mm
Battery voltage	12 V

Weight and Dimensions

Weight	125 g
