UNI-T UT20B User Manual

Rules For Safe Operation (2)
l When the Meter working at an effective voltage over 60V in DC or 30V rms
in AC, special care should be taken for there is danger of electric shock.
l Use the proper function and range for your measurements.
l Do not use or store the Meter in an environment of high temperature,
humidity, explosive, inflammable and strong magnetic field. The
performance of the Meter may deteriorate after dampened.
l When using the test leads, keep your fingers behind the finger guards.
l Disconnect circuit power and discharge all high-voltage capacitors before
testing resistance, diodes or current.
l Before measuring current, check the Meter's fuses and turn off power to
the circuit before connecting the Meter to the circuit.
l Replace the battery as soon as the battery indicator
appears. With a
low battery, the Meter might produce false readings that can lead to electric
shock and personal injury.
l Turn the Meter power off before opening the Meter case.
l When servicing the Meter, use only the same model number or identical
7
Model UT20B: OPERATING MANUAL

UNI-T UT20B Specifications

General

Diode test	Yes
Product type	Digital multimeter
DC current range	0.2 - 2 A
DC voltage range	0.2 - 300 V
Statistic function	Maximum
Basic accuracy (DC current)	±(2.5%+10)
Basic accuracy (DC voltage)	±(1.5%+2)
Basic accuracy (resistance)	±(2.5%+5)
Dimensions (WxDxH)	52 x 26 x 95 mm
Battery voltage	12 V

Weight and Dimensions

Weight	125 g
