Measurement Operation (12)
25
Model UT33A: OPERATING MANUAL
l When diode testing has been completed, disconnect the connection between the
testing leads and the circuit under test.
Testing for Continuity
To test for continuity, connect the Meter as below:
1. Insert the red test lead into the VΩ mA terminal and the black test lead into the
COM terminal.
2. Set the rotary switch to .
3. Press SELECT button to select continuity measurement mode.
4. Connect the test leads across with the object being measured.
The buzzer sounds if the resistance of a circuit under test is less than 100Ω.
