Accuracy Specifications(2)
31
Model UT33A: OPERATING MANUAL
Range Resolution
4V
40V
400V
500V
Accuracy
Overload Protection
(1.2%+3)
500V DC or AC
1mV
10mV
100mV
1V
(1.5%+5)
B. AC Voltage
Remarks:
l Input impedance: approx. 10MΩ.
l Displays effective value of sine wave (mean value response).
l Frequency response 40Hz ~ 400Hz.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the UNI-T UT33A and is the answer not in the manual?

UNI-T UT33A Specifications

General IconGeneral
DC Voltage Range200mV/2V/20V/200V/500V
AC Voltage Range200V/500V
DC Current Range200μA/2mA/20mA/200mA/10A
Resistance Range200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ
DisplayLCD
Display Count1999
Diode TestYes
Continuity TestYes
Data HoldYes
Battery Test1.5V/9V
Battery Type9V (6F22)
Weight156g
