UNI-T UT60E User Manual

The Meter Structure (see figure 1)
(figure 1)
1 LCD Display
2 Functional Buttons
3 Rotary Switch
4 HzV
Input Terminal:
Input for voltage, frequency/duty cycle, resistance, diode,
continuity and capacitance measurements.
5 COM Input Terminal:
Return terminal for all measurements.
Model UT60B
:
Input Terminal:
Input for 0.1 A to 400.0mA current measurements.
Input Terminal:
Input for 0.1 A to 400.0mA current measurements and
temperature testing.
7 10A Input Terminal:
Input for 0.01A to 10.00A current measurements.
7
Model UT60B/C/E: OPERATING MANUAL

UNI-T UT60E Specifications

General

Backlight	Yes
Product type	Digital multimeter
Frequency range	0.01 - 10000 kHz
AC current range	0.4 - 10 A
AC voltage range	4 - 750 V
DC voltage range	0.4 - 1000 V
Dimensions (WxDxH)	85 x 177 x 40 mm
Battery voltage	9 V

Weight and Dimensions

Weight	320 g
