Model UT71A/B/C/D/E: OPERATING MANUAL
Table 2-1. Rotary Switch Selections
Rotary
Switch Position
Rotary Switch Function Blue Key Function
Turn the Meter off
DC voltage measurement
AC voltage measurement
AC or DC voltage measurement
DC millivoltage measurement
DC millivoltage measurement
Resistance measurement
Power measurement
Capacitance measurement
Centigrade temperature measurement
None
None
None
Toggle between AC or DC voltage measurement
Frequency measurement
Frequency signal duty cycle measurement
None
Diode test
Continuity test
None
None
Fahrenheit temperature measurement
OFF
V
Hz %
mV
ºC ºF
l
l
V
V
l
l
mV
(UT71B/C/D)
W (UT71E only)
(UT71B/C/D )
(UT71A/B/C/D )
(UT71A/B/C/D )
(UT71E only)
(UT71A/E)

UNI-T UT71E Specifications

General

Data hold	Yes
Product type	Digital multimeter
Frequency range	0.04 - 40000 kHz
AC current range	0.4 - 10 A
AC voltage range	4 - 1000 V
DC voltage range	0.4 - 1000 V
Capacitance range	40 - 40000 nF
Statistic function	Maximum, Minimum
Basic accuracy (frequency)	0.01%+8
Basic accuracy (DC current)	0.08%+8
Basic accuracy (DC voltage)	0.025%+5
Basic accuracy (resistance)	0.3%+8
Basic accuracy (capacitance)	1%+20
Temperature measurement range	-40 - 1000 °C
Dimensions (WxDxH)	93 x 40 x 200 mm
Battery voltage	9 V

Weight and Dimensions

Weight	384 g
