UNI-T UT71E User Manual

2
Model UT71A/B/C/D/E: OPERATING MANUAL
29
29
30
30
30
32
34
35
37
39
41
43
44
45
47
47
47
48
48
3.
4.
CHAPTER TITLE PAGE
Analogue Bar Graph
Using MAX MIN
Making Measurements
Introduction
A. Measuring Voltages
B. Measuring Currents
C. Measuring Resistance
D. Testing for Continuity
E. Testing Diodes
F. Measuring Capacitance
G. Measuring Frequency / Duty Cycle
H. Measuring Temperature
I. 4~20mA loop current as % readout
J. Power Measurement
Using Stores, Recall and Send Features
Introduction
Storing and Clearing Readings
Recalling Stored Readings
Using Send

UNI-T UT71E Specifications

General

Data hold	Yes
Product type	Digital multimeter
Frequency range	0.04 - 40000 kHz
AC current range	0.4 - 10 A
AC voltage range	4 - 1000 V
DC voltage range	0.4 - 1000 V
Capacitance range	40 - 40000 nF
Statistic function	Maximum, Minimum
Basic accuracy (frequency)	0.01%+8
Basic accuracy (DC current)	0.08%+8
Basic accuracy (DC voltage)	0.025%+5
Basic accuracy (resistance)	0.3%+8
Basic accuracy (capacitance)	1%+20
Temperature measurement range	-40 - 1000 °C
Dimensions (WxDxH)	93 x 40 x 200 mm
Battery voltage	9 V

Weight and Dimensions

Weight	384 g
