4
UTD1000 User Manual
Resistance measurement
DC voltage measurement
AC voltage measurement
(45Hz
400Hz)
DC current measurement
(external module)
AC current measurement
(45Hz
00Hz)
(external module)
Capacitance measurement
Range : 600Ω, 6kΩ, 60kΩ, 600kΩ, 6MΩ, 60MΩ
600Ω/6MΩ/60MΩ: ±(1.5%+5 digits),
6KΩ/60KΩ/600KΩ: ±(1.2%+5 digits)
Range : 600mV, 6V, 60V, 600V, 1000V
Precision : ± (1% + 5 digits)
Range : 600mV, 6V, 60V, 600V, 700V
600mV/6V/60V/600V/700V :±(1.2%+5 digits),Frequency:≤200Hz
:±(1.5%+5 digits),Frequency:≥200Hz
Range : 6mA, 60mA, 600mA, 6A
6mA/60mA/600mA:±(1.2%+5 digits)
6A :±(1.5%+5 digits)
Range : 6mA, 60mA, 600mA, 6A
6mA/60mA/600mA:±(2%+5 digits)
6A:±(2.5%+5 digits)
Range : 6nF, 60nF, 600nF, 6μF, 60μF, 600μF, 6mF
6nF/6mF:±(5%+10 digits)
60nF/600nF/6μF/60μF/600μF:±(4%+5 digits)
Digital Multimeter (It only suits for battery power supply)
