UTD1000 User Manual
Setting the Display Mode
Press [SCOPE] then [F3] to access the display menu shown in Table 2-7 below.
Table 2-7 Display menu
Function Menu
Type
Duration
Format
Setup
Vector
Dot
OFF
2s
5s
Infinity
YT
XT
Explanatory Note
Sampling points are linked for display.
Sampling points are directly displayed.
Waveform on the screen is refreshed at normal rate.
Waveform on the screen is maintained for 2 seconds and then refreshed.
Waveform on the screen is maintained for 5 seconds and then refreshed.
Waveform on the screen remains on display. New data will be added
continuously.
Operating mode of the Oscilloscope.
X-Y is the display mode; A input signal is X signal, B input signal is Y
signal.
