Quick Start Guide UTS3000B Series
16 / 18
Instruments.uni-trend.com
3. Select purchased secret key and then press [ENTER] to confirm.
Touch Operation
Spectrum analyzer has 10.1 inch multipoint touch screen for various gesture operating, which includes,
Tap the top right on the screen to enter the main menu.
Slide up/down, left/right in waveform area to change the center frequency of X axis or reference level
of Y axis.
Zoom two points in waveform area to change the sweep width of X axis.
Tap parameter or menu on the screen to select and edit it.
Turn on and move the cursor.
Use auxiliary quick key to perform common operation.
Use [Touch/Lock] to turn on/off touch screen function.
Remote Control
The UTS3000B series spectrum analyzers support communication with computers via USB and LAN
interfaces. Through these interfaces, users can combine the corresponding programming language or
NI-VISA, using the SCPI (Standard Commands for Programmable Instruments) command to remotely
program and control the instrument, as well as interoperate with other programmable instruments that
support the SCPI command set.
For more information about the installation, remote control and programming, please refer to official site
http:// www.uni-trend.com UTS3000B Series Programming Manual.
Help Information
The spectrum analyzer's built-in help system provides help information for each function button and menu
control key on the front panel.
● Touch the left of the screen “ ”, help dialog box will pop out on the center of the screen. Tap support
function to get more detailed help description.
● After help information displayed on the center of the screen, tap “×” or other key to close the dialog box.
Troubleshooting
This chapter lists the possible faults and troubleshooting methods of the spectrum analyzer.
Please follow the corresponding steps to handle it, if these methods is not work, please contact UNI-T and
provide your machine.
Device information (acquisition method: [System] >System Information)
1. After press the power soft switch, the spectrum analyzer still display a blank screen, and nothing is displayed.
a. Check whether the power connector is properly connected and the power switch is turned on.
