Instruction for the installer
ALKON 09 R/C 18
ALKON 09 R/C 24
3.20 - VARIATION OF OUTPUT RANGE
It is possible to adjust the maximum input by reducing the fan
speed.
With the parameter HP:
rpm x 100 ex. 70 = 7000 rpm
For example: with the parameter HP settled on 82, the
correspondent maximum input will be of 16 kW (Alkon 09
18kW).
For example: with the parameter HP settled on 80, the
correspondent maximum input will be of 20 kW (Alkon 09
24kW).
0 2 4 6 8 01121416182022242628303234363840
Maximum imput
0
100
50
7,14
85,70
14,28
21,42
28,56
35,70
42,84
57,14
64,28
71,42
78,56
92,84
0 2 4 6 8 01121416182022242628303234363840
Maximum imput
0
100
Output range
50
7,14
85,70
14,28
21,42
28,56
35,70
42,84
57,14
64,28
71,42
78,56
92,84
