GREASING POINTS
Inching and brake pedal shafts
•
(1 point) ............................................................. A
Rear axle (8 points in all)
•
................................... B
(Axle support (2), king pin (3), knuckle (3))
Mast support (2 points)
•
...................................... C
Tilt cylinder (4 points)
•
......................................... D
Inner and outer channels in areas
•
which come in contact with end rollers:
Apply grease with brush .................................... E
4-35
