Truck model
Leading particulars
FG25T3C FD25T4C FD25T3CZ
Rated load kg (lbs) 2500 (5000)
Basic load center mm (in.) 500 (24)
Max. height A mm (in.) 3000 (118.1)
Free lift B mm (in.) 110 (4.3)
Fork lifting speed mm/s (fpm)
No load 580 (114.2) 600 (118.1) 580 (114.2)
Loaded 520 (102.4) 530 (104.3) 550 (108.3)
Traveling speed km/h (mph)
Forward 1st speed 19.0 (11.8) 19.0 (11.8) 19.0 (11.8)
2nd speed --- --- ---
Reverse 1st speed 19.0 (11.8) 19.0 (11.8) 19.0 (11.8)
2nd speed --- --- ---
Gradeability (1.6 km/h, 1.0 mph) %
No load 18 18 18
Loaded 24 23 20
Min. turning radius C mm (in.) 2240 (88.2)
Min. intersecting aisle width mm (in.) 2010 (79.1)
Overall length D mm (in.) 3625 (142.7)
Overall width E mm (in.) 1150 (45.3)
Overall height (mast) F mm (in.) 2030 (79.9)
(overhead guard) G mm (in.) 2070 (81.5) EXC 2130 (83.9)
Overall height, mast raised H mm (in.) 4030 (158.7)
Wheelbase mm (in.) 1600 (63.0)
Tread, front mm (in.) 970 (38.2)
rear mm (in.) 970 (38.2)
Fork size mm (in.)
length (K) x width (M) x thickness (L) 1070 x 122 x 40 (42.1 x 4.8 x 1.6)
Fork spacing P mm (in.) 245 - 1020 (9.6 - 40.2)
Ground clearance (mast) mm (in.) 110 (4.3)
Truck weight kg (lbs) 3530 (7780) 3640 (8020) 3630 (7990)
Mast weight kg (lbs) 595 (1312)
Engine
Model GCT K21 gasoline engine
Isuzu C240PKJ-31 diesel engine
Type 4-cycle water cooling
4-cycle water
cooling
4-cycle water cooling
Total displacement
ℓ
(cu. in.) 2.065 (126.4) 2.434 (148.5) 2.369 (145)
Rated output 34.6 kW (48.6 PS)/2250 rpm
35.5 kW
(48.3 PS)/2600 rpm
35.4 kW/2500 rpm
Maximum torque
153.5 N-m (15.7 kgf-m)/1600 rpm
156.5 N-m
(16 kgf-m)/1600 rpm
140 N-m/1800 rpm
Tire
Front 7.00-12-12PR(I)
Rim size 5.00S-12DT
Inflation pressure 700 kPa, 7.0 kgf/cm
2
(100 psi)
Rear 6.00-9-10PR(I)
Rim size 4.00E-9DT
Inflation pressure 700 kPa, 7.0 kgf/cm
2
(100 psi)
5-4
SPECIFICATIONS
Kubota V2403 diesel engine
