UniCarriers FD25T4C - Page 144

Truck model
Leading particulars
FG30T3C FD30T4C FD30T3CZ
Rated load kg (lbs) 3000 (6000)
Basic load center mm (in.) 500 (24)
Max. height A mm (in.) 3000 (118.1)
Free lift B mm (in.) 165 (6.5)
Fork lifting speed mm/s (fpm)
No load 490 (96.4) 490 (96.5) 470 (92.5)
Loaded 440 (86.6) 450 (88.6) 450 (88.6)
Traveling speed km/h (mph)
Forward 1st speed 19.5 (12.1) 19.5 (12.1) 19.5 (12.1)
2nd speed --- --- ---
Reverse 1st speed 19.5 (12.1) 19.5 (12.1) 19.5 (12.1)
2nd speed --- --- ---
Gradeability (1.6 km/h, 1.0 mph) %
No load 20 20 20
Loaded 18 19 18
Min. turning radius C mm (in.) 2400 (94.5)
Min. intersecting aisle width mm (in.) 2110 (83.1)
Overall length D mm (in.) 3775 (148.6)
Overall width E mm (in.) 1225 (48.2)
Overall height (mast) F mm (in.) 2075 (81.7)
(overhead guard) G mm (in.) 2090 (82.5) EXC 2150 (84.6)
Overall height, mast raised H mm (in.) 4250 (167.3)
Wheelbase mm (in.) 1700 (66.9)
Tread, front mm (in.) 1000 (39.4)
rear mm (in.) 970 (38.2)
Fork size mm (in.)
length (K) x width (M) x thickness (L) 1070 x 125 x 45 (42.1 x 4.9 x 1.8)
Fork spacing P mm (in.) 250 - 1090 (9.8 - 42.9)
Ground clearance (mast) mm (in.) 140 (5.5)
Truck weight kg (lbs) 4135 (9110) 4245 (9360) 4240 (9340)
Mast weight kg (lbs) 660 (1455)
Engine
Model GCT K21 gasoline engine
Isuzu C240PKJ-31 diesel engine
Type 4-cycle water cooling
4-cycle water cooling
4-cycle water cooling
Total displacement
ℓ
(cu. in.) 2.065 (126.4) 2.434 (148.5) 2.369 (145)
Rated output 34.6 kW (48.6 PS)/2250 rpm
35.5 kW
(48.3 PS)/2600 rpm
35.4 kW/2500 rpm
Maximum torque
153.5 N-m (15.7 kgf-m)/1600 rpm
156.5 N-m
(16 kgf-m)/1600 rpm
140 N-m/1800 rpm
Tire
Front 28x9-15-12PR(I)
Rim size 7.00T-15
Inflation pressure 700 kPa, 7.0 kgf/cm
2
(100 psi)
Rear 6.50-10-10PR(I)
Rim size 5.00F-10
Inflation pressure 700 kPa, 7.0 kgf/cm
2
(100 psi)
5-5
SPECIFICATIONS
Kubota V2403 diesel engine
