14SERVICING AND MAINTENANCE
52
Location Explanation
C Spring-mounted drive unit – link
bearings, 12 grease nipples
D Hydraulic oil
E Castor wheel - sliding bearings, 2
grease nipples
F Gearbox oil
G Platform, 2 grease nipples
Lubrication chart PLP CD
1. 500 hr service 2. Annual service
Instruction Handbook PLL, PLE, PSL, PSD, PS, PSH, PLP, TS — D002652, B, GBR, ForTranslation
