SERVICING AND MAINTENANCE14
55
PL*/PS* fuses
Designations Heavy current (A) Use
F1 100 Traction motor
F2 80 Pump motor
F3 7,5 Manoeuvring
Table 6. PL*/PS* fuses
PS, PSH fuses
Designations Heavy current (A) Use
F1 100 Traction motor
F2 125 Pump motor (PS)
160 Pump motor (PSH)
F3 7,5 Manoeuvring
Table 7. PS, PSH fuses
PLP fuses
Designations Heavy current (A) Use
F1 250 Traction motor
F2 250 Pump motor
F3 7,5 Manoeuvring
Table 8. Fuses
Designations Heavy current (A) Use
F4 5 For additional
equipment. Max. 120
W
F5 25 Servo steering
TS fuses
Model Heavy current (A) Use
TS 1.1 kW, TS 2 kW 3 Manoeuvring
TS 1.1 kW, TS 2 kW 7,5 Manoeuvring
TS 1.1 kW, TS 2 kW 250 Pump motor
TS 1.1 kW 100 Traction motor
TS 2 kW 160 Traction motor
Table 9. TS fuses
Maintenance instructions
Genuine replacement parts
Genuine Parts
The reliability that we promise is contingent upon using original
spare parts. Only our genuine replacement parts guarantee
correct operation, long life and the right to a warranty.
