TS components requiring lubrication
Location Explanation
A1 Mast section - roller surfaces and slide surfaces
A2 Thrust rollers - all
B Lift chains - all
C Fork carriage - support rollers
D Fork carriage – slide surfaces
E Bogie – axle (unloaded)
F Battery rollers
G Guide ring
H Gearbox
I Speed and brake controls – slide surfaces and springs
lubricated
J Attachment gas spring steering arm
K Steering arm housing
L Upper/lower guide bearings lubricated
M Hydraulic tank
N Steering chain
O Castor wheel, sliding bearings, wheel bearings
Symbol key lubrication chart
Symbol Explanation Symbol Explanation
Oil filter and air filter,
change
Hydraulic oil, oil filter
and air filter, change
Gearbox oil, check Gearbox oil, change
Grease Only cold store
version
Chain spray Chain spray/oil
Applicable in general for the symbols:
Unfilled symbol, check lubrication.
Filled symbol – Change.
Fuses
General
WARNING!
Fuses should be changed by an authorised service
technician.
WARNING!
Always switch off the current by pulling out the
battery plug when changing fuses.
