16DIMENSIONS
76
Figure 14. Positions for dimensions PLE
Figure 15. Positions for dimensions PSD/PSL
Measurements PLE PSD 125/160 PSL
D 600 600 600
H4 730
H3 880
Table 11. Truck type and dimensions in mm
Instruction Handbook PLL, PLE, PSL, PSD, PS, PSH, PLP, TS — D002652, B, GBR, ForTranslation
