User and installation manual
Réf : 004057-02 Page : 3/17
Technical specifications
This control box is compatible with following motors:
AN1244: PL3210, PL1218, DL3010 and DL1318
AN1274: PL6010, PL3218, PL7710, DL6010, DL7710 and DL3018
• « Pulse mode » or « Hold mode » can be selected independently on both directions (open/close).
• Overload detection in case of motor slow down during cover operation
• Security Loop (for emergency stop or alarms coming from sensors)
• Auxiliary Relay (for electrolyser or pump management)
• One-digit display for alarm notification and troubleshooting.
FUSES CARACHTERISTICS:
AN1244
F1 = Fuse ATO 10A
F2 = Fuse 5x20 3.15A Time lag
AN1274
F1 = Fuse ATO 15A
F2 = Fuse 5x20 4A Time lag
CHARACTERISTICS AN1244 AND1274 Unit
Power feed tension 230 230 V AC
Frequency 50 50 Hz
Monophasic AC Network L/N/PE L/N/PE
Maximum power 210 360 VA
Zero load tension 30 30 V DC
Maximum load current 10 15 A
Dimension (HxLxP) 291x241x87 291x241x88 mm
Weight 3,5 4,7 kg
Waterproof class IP50 IP50
Operation temperature range 0 to 50 de 0 to 50 °C
Admissible humidity 0 to 85 de 0 to 85 %
