34
6
Place the mounting slots over
the pins on the wall plate.
7
Slide the base down to lock it
into place.
Removing the wall-mount bracket
At the bottom of the base, pinch the
two “nose” of the wall-mount bracket
as ahown, and then slide the bracket
away from the base.
Note: Mounting the phone directly on the wall
• Be sure the wall is capable of supporting the weight of the phone, and
use the proper type of anchoring device for the wall material.
• Insert two #10 screws (minimum length of 35mm, not supplied) into the
wall, 100mm apart.
• Leave the screw heads 3mm away from the wall to allow room for
mounting the phone.
• Align the mounting slots over the screws and slide the base down into
place as shown above.
