15
14
13
21
22
17
16
18
19
24
28
20
23
25
26
27
TORS
1 Antenna 16 DCS ON Indicator
2 PTT(Push-To-Talk) Key 17 Scan Indicator
3 Monitor Key 18 Memory Indicator
4 Keylock/Call Key 19 Priority Channel Indicator
5 Memory/Scan Key 20 CTCSS ON Indicator
6 Channel/Power Hi-Lo Key 21 Battery Level Indicator
7 Speaker 22 HI Transmit Indicator
8 Headset Jack 23 Lo Transmit Indicator
9 Select/Power On-Off Key 24 CTCSS and DCS Code/Volume Level Indictor
10 Volume/Select Up Key 25 Volume Setting Indicator
11 Volume/Select Down Key 26 VOX Indicator
27 Busy Channel Lockout Indicator
12 Microphone
13 Receive Indicator
28 Keypad Lock Indicator
14 Transmit Indicator
29 Charging LED
15 Channel Indicator
(1)
10
11
12
CONTROL & INDICATORS
INCLUDED IN YOUR PACKAGE:
• uh047sx Radio • Charging Cradle with AC Adaptor
• Operating Guide • NiMH Battery Pack
• Belt Clip • External Speaker Mic
OPTIONAL ACCESSORIES
• VOX Earset
• Carry Case
• VOX Headset
29
