Uniden UH089NB User Manual

UH089NB
5
Controls & Connectors
UNIDEN UH089NB UHF CB Transceiver
1 3
5 6
4
2
7 10 118 9 12
1
Liquid Crystal Display (LCD)
2
Rotary Channel Selector
3
On/Off Volume & Squelch
4
Push to Talk (PTT) Switch
5
Call Button
6
Instant Button
7 Menu/Enter
- Select Button
8
SCAN -
Scan On/Off
OS/GS - Open Scan/
Group Scan
9
DIM - Backlight Dimmer
10
MEM - Memory Scan Channels
11 MON -
DCS/CTCSS - Monitor
and DCS/CTCSS Tone button
12
DUP - Duplex On/Off
13
UHF Antenna Connection
14
External Speaker Jack
15
Power Input (13.8V DC)
EXT.SP.
13
14
15
