US-24, US-48 Quick Start Guide
https://dl.ui.com/qsg/US-24_US-48/US-24_US-48_EN.html
10/13
US-24
Weight
Rack-Mount Brackets Included 2.60 kg (5.70 lb)
Rack-Mount Brackets Excluded 2.51 kg (5.53 lb)
Enclosure Characteristics SGCC Steel
Max. Power Consumption 24W
Total Non-Blocking Line Rate 26 Gbps
Power Method
AC 100-240 VAC / 50-60 Hz Universal Input
DC DC 25W, 25 to 16V, with 2.5 mm
DC Power Inline Connector
Power Supply AC/DC Internal 20W DC
ESD/EMP Protection Air ± 24 kV, Contact ± 24 kV
Operating Temperature -5 to 40° C (23 to 104° F)
Operating Humidity 5 to 95% Non-Condensing
Shock and Vibration ETSI300-019-1.4 Standard
Interfaces
Networking (24) 10/100/1000 Mbps RJ45 Ethernet Ports
(2) 1 Gbps SFP Ethernet Ports
Management (1) RJ45 Serial Out-of-Band, Ethernet In-Band
LEDs Per Port
RJ45 Data Ports Speed/Link/Activity
SFP Data Ports Speed/Link/Activity
Rack Mount Yes, 1U
Certifications CE, FCC, IC
US-48
Dimensions 443 x 43 x 286 mm (17.44 x 1.69 x 11.26")
Weight
Rack-Mount Brackets Included 3.65 kg (8.06 lb)
Rack-Mount Brackets Excluded 3.56 kg (7.85 lb)
Enclosure Characteristics SGCC Steel
Max. AC Power Consumption 56W
Total Non-Blocking Line Rate 70 Gbps
Power Method
AC 100-240 VAC / 50-60 Hz Universal Input
DC DC 56W, 25 to 16V, with 2.5 mm
DC Power Inline Connector
Power Supply AC/DC Internal 56W DC
US-24, US-48 Quick Start Guide
×
Click for
Table of Contents

UniFi US-24 Specifications

General

Total Non-Blocking Throughput	26 Gbps
Switching Capacity	52 Gbps
Forwarding Rate	38.69 Mpps
Max. Power Consumption	25W
Rackmount	Yes
Operating Temperature	-5 to 40° C (23 to 104° F)
Operating Humidity	5 to 95% Noncondensing
Management Interface	Ethernet In-Band
Certifications	CE, FCC, IC
ESD/EMP Protection	Air: ± 24 kV, Contact: ± 24 kV
Power over Ethernet	No
Ports	24 x Gigabit RJ45
Power Method	AC Input
Power Supply	Internal
LEDs Per Port	Speed/Link/Activity
Networking Interface	(24) 10/100/1000 Mbps RJ45 Ports (2) 1 Gbps SFP Ports
