RJ45 ports support Power over Ethernet (PoE) and 10/100/1000 Ethernet connections
7. SFP+ (Ports 1 – 2)
Hot-swappable SFP+ ports support 1/10 Gbps connections.
8. SFP (Ports 1 – 2)
Hot-swappable SFP ports support 1 Gbps connections
9. Reset Button
This button serves two functions for the UniFi Switch:
Restart Press and release the Reset button quickly.
Restore to Factory Default Settings Press and hold the Reset button for more than five seconds.
10. Console Port
RJ45 serial console port for Command Line Interface (CLI) management. Use an
RJ45-toDB9, serial console cable, also known as a rollover cable, to connect the
Console port to your computer. Then configure the following settings as needed:
Baud rate 115200
Data bits 8
Parity NONE Stop bits 1
Flow control NONE
11. Power Port
Connect the included Power Cord to the Power port.
Hardware Installation
