The Booth Output provides for independent local monitoring of the Main Mix buss and
is not aected by the Main Mix Level control. It features a two-band EQ and a level
control.
The headphone output is used for previewing the pre-fader signal level feeding the
input channels, and is acve when any Cue buon is pressed (see page 11). The
headphone output also features an “Add-Mix” control.
Booth Level – Adjusts the signal level of the Booth Outputs from o to +6dBu when
rotated fully clockwise. For best signal to noise rao (SNR), set the level with the
pointer at or above the 12 o’clock posion.
Booth EQ – A two-band shelving EQ oering +/-6dB boost/cut at 100Hz and 5kHz.
Phones Level– Adjusts the level of the headphone output. The Orbit.6 is ed with a
powerful high-quality headphone amplier opmised for use with headphones having
an impedance between 33ohms to 170ohms. Headphones with impedances above or
below the recommended impedance should be avoided, and in parcular headphones
with impedances below 33ohms could cause damage to the circuitry.
WARNING! Avoid operang the mixer with headphones at high volume or
for extended periods of me as this can contribute to severe hearing loss!
Add Mix – The Add Mix control sets the level of the main mix summed with the Cue
Mix. When the knob is fully an-clockwise, only the channel Cue signal will be heard in
the headphones. Turning the Add Mix knob clockwise increasingly adds the mix signal
to the headphones allowing the operator to audion how the Cued channel signal will
sound in the mix before the Channel fader is raised.
