Mic Select – Channel Six can be routed to the microphone input (located on the rear
panel) by switching the front panel toggle switch to “Line A/Mic” and by pressing the
“Ch Six Line A to Mic” buon on the rear panel.
The Microphone input is designed to work with any good quality dynamic microphone,
such as the Shure SM58. By default, the microphone input isn’t phantom powered,
but this funcon can be acvated by changing an internal jumper link - contact Union
Audio or an authorised service agent for more details.
Rear Panel Controls
Ch Six Line A to Mic – Pressing in this buon routes the Microphone Input to Channel
Six Line A - NOTE that the LINE A RCA input on Channel Six will be deacvated.
MIC Input XLR – Balanced XLR Input. Pin1 = Ground, Pin 2 = + Hot, Pin 3 = - Cold
Mic Trim– Sets the gain of the pre-amplier from +15dB to +55dB to suit the
microphone used.
Mic EQ– Two-band equalizer to adjust the tonality of the microphone input or as an
aid in liming feedback.
REAR
Microphone Input
