Union Audio Orbit.6 - Table of Contents; Index

6
Contents
Warranty 3
Safety Instrucons 4 - 5
Index 6
About Orbit.6 7
Why Discrete circuitry? 8
Front and Rear Line Drawing 9
Input Channel Controls 10 - 11
Microphone Input 12
Master Secon 13
Booth and Headphones 14
Rear Panel Input Connecons 15
Mixer Output Connecons 16
Record and Auxiliary connecons 17
Applicaon Diagram 18
Block Diagram 19
Technical Specicaon 20
Notes on Cable Types 21
Index
Contents connued
Europa Power Supply 22
Connecng the PSU to the mixer 23
Care of the Mixer 24
Mixer Dimensions 25
Europa Dimensions 26
Service Record and Notes 27
