ULA
PLANNING AND
ASSEMBLY
INSTALLATION MANUAL
SYSTEM CERTIFICATION
PAGE
20
APPENDIX A
Electrical Bonding and Grounding Test Modules
The list below is not exhaustive of compliant modules but shows those that have been evaluated and found to be electrically compatible with the UNIRAC LARGE ARRAY system.
The modules selected for UL 2703 bonding and grounding testing represent the broadest possible range of modules on the market. The tests were performed for each specic bond-
ing location using representative module frame prole sections. The tests performed cover the following basic module parameters:
• The frame prole must not have any feature that might interfere with the bonding devices that are integrated into the racking system
• Use with a maximum over current protection device OCPD of 30A
• Unless otherwise noted, all modules listed above include all wattages and specic models within that series. Variable wattages are represented as "xxx"
• Items in parenthesis are those that may or may not be present in a compatible module's model ID
• Slashes "/" between one or more items indicates that either of those items may be the one that is present in a module's model ID
Manufacture Module Model / Series
REC
RECxxxAA (BLK/Pure)
RECxxxNP (N-PEAK)
RECxxxNP2 (Black)
RECxxxPE, RECxxxPE72
RECxxxTP, RECxxxTP72
RECxxxTP2(M/BLK2)
RECxxxTP2S(M)72
RECxxxTP3M (Black)
RECxxxTP4 (Black)
Renesola All 60-cell modules
Risen
RSM Series
RSM110-8-xxxBMDG
S-Energy SN72 & SN60 Series
Seraphim
SEG-(6PA/6PB/6MA/6MA-HV/6MB/E01/E11)
SRP-(6QA/6QB)
SRP-xxx-6MB-HV, SRP-320-375-BMB-HV,
SRP-xxx-BMC-HV, SRP-390-450-BMA-HV,
SRP-xxx-BMZ-HV, SRP-390-405-BMD-HV
Sharp NU-SA & NU-SC Series
Silfab
SLA-M, SLA-P, SLG-M, SLG-P & BC Series
SILxxx(BL/NL/NT/HL/HN/ML/BK/NX/NU/HC)
SolarEver SE-166*83-xxxM-120N
Solaria
PowerXT-xxxR-(AC/PD/BD)
PowerXT-xxxC-PD
PowerXT-xxxR-PM (AC)
Solartech STU HJT, STU PERC & Quantum PERC
Manufacture Module Model / Series
SolarWorld Sunmodule Protect, Sunmodule Plus/Pro
Sonali
SS-M-360 to 390 Series,
SS-M-440 to 460 Series,
SS-M-430 to 460 BiFacial Series,
SS-M-390 to 400 Series.
Sun Edison F-Series, R-Series
Suniva MV Series & Optimus Series (35mm)
SunPower
AC, X-Series, E-Series & P-Series,
SPR-Mxxx-H-AC
Suntech STP
Talesun
TP572, TP596, TP654, TP660,
TP672, Hipor M, Smart, TD6I72M
Tesla SC, SC B, SC B1, SC B2, TxxxS
Trina
PA05, PD05, DD05, DD06, DE06
PD14, PE14, DD14, DE14, DE15
TSMC TS-150C2 CIGSw
Universal Solar
UNI4xx-144BMH-DG
UNI5xx-144BMH-DG
UNIxxx-108M-BB
UNIxxx-120M-BB
UNIxxx-120MH
Manufacture Module Model / Series
Upsolar UP-MxxxP, UP-MxxxM(-B)
URECO
D7Kxxx(H7A/H8A), D7Mxxx(H7A/H8A)
FAKxxx(C8G/E8G), FAMxxxE7G-BB
FAMxxxE8G(-BB)
F6MxxxE7G-BB
FBMxxxMFG-BB
Vikram Eldora, Somera, Ultima
Vina
VNS-72M1-5-xxxW-1.5,
VNS-72M3-5-xxxW-1.5,
VNS-144M1-5-xxxW-1.5,
VNS-144M3-5-xxxW-1.5,
VNS-120M3-5-xxxW-1.0
VSUN
VSUN xxx-60M-BB, VSUNxxx-72MH
VSUN 4xx-144BMH
VSUN4xx-144BMH-DG
VSUN5xx-144BMH-DG
VSUNxxx-108M-BB
VSUNxxx-120M-BB
Waaree Ahnay Series Bi-33
Winaico WST & WSP Series
Yingli YGE & YLM Series
ZNShine Solar
ZXM6-72 Series
ZXM7-SH108 Series
