1. UNPACKAGING
Please make sure that the packaging is undamaged and the product
has not suffered from rough handling during transportation,
otherwise we highly recommend to contact your Authorised Dealer
for advice before proceeding to install the unit.
Carefully remove your CD player and all the accessories from the
carton.
Inside the package you’ll find:
- 1 Unico Primo amplifier
- 1 power supply cable
- 1 user manual
- 1 remote control handset
IMPORTANT! After unpacking please allow some hours
before operating the device in order to let it adapt to the
room temperature. This time is needed to prevent any
possible damage due to the condensation which can
eventually form during transportation. Please note, that
condensation can form every time the amplifier is moved
from a cold to a warm place.
Keep all packing materials: every time you will need to transport the
Unico Primo, its original purpose-designed carton will provide the
safest packing.
2. INSTALLATION
The Unico Primo should be positioned in a safe place on a plane
surface.
Adequate clearance must be left above and around the device to
guarantee a correct ventilation.
We also suggest to leave enough free space behind your Unico
Primo to allow the connecting cables sufficient room to bend
without crimping or strain, and we strongly recommend not to place
the device directly on a power amplifier top surface or, in general,
close to a heat source.

Other manuals for Unison Research Unico Primo

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Unison Research Unico Primo and is the answer not in the manual?

Unison Research Unico Primo Specifications

Power Output IconPower Output
power output80W RMS on 8Ω both channels driven
power consumption380W max
Frequency and Impedance IconFrequency and Impedance
frequency response-0.1dB @ 10Hz / -0.5dB @ 100kHz
input impedance47kΩ
feedback factor10dB
Phono Stage IconPhono Stage
phono input impedance MM47kΩ // 220pF
phono input impedance MC100Ω // 440pF
phono gain MM40dB
phono gain MC50dB
phono gain setting+0dB / +10dB
phono max input voltage120mV @ 1kHz
phono THD0.09% @ 5mV, 1kHz, MM
Dimensions and Weight IconDimensions and Weight
dimensions17.1in x 3.5in x 17in
weight31lb
